Professional rain gauge
It features a self-emptying system. The data can be analyzed with Smartyplanet.
The SP-300.023 professional rain gauge is the ideal solution for measuring precipitation in adverse conditions.
It is the perfect rain gauge for weather stations, forest control, water treatment, or other applications.
The professional rain gauge has an integrated magnet that allows the bucket to empty quickly and return to its initial position.
At the bottom of the rain gauge there is a space for a data logger. Thanks to its full compatibility, the collected data can be analyzed by the Smartyplanet web platform.
Category: Rain, Rain, Smarty Meteo, Smarty Agro, Smarty River, Smarty Snow, Traffic, Liquid Precipitation
Description
Applications
Technical characteristics
The SP-300.023 professional rain gauge is the ideal solution for measuring precipitation in adverse conditions.
It has several applications in the field of meteorology.
It is designed so that the water passing through the funnel (50cm2) is directed towards a tilting bucket held by a magnet that ensures movement so that this bucket is self-emptying.
The magnet exerts enough tension to make the self-emptying movement fast and the cube can return to its initial position in less than 300ms.
The bucket is made of POM, a material that prevents dust and dirt from sticking to the scoop. This allows the collected water to be released more easily.
At the bottom of the professional rain gauge there is a space for a data logger. Thanks to its full compatibility, the collected data can be analyzed by the Smartyplanet web platform.
This rain gauge is easy to install and requires minimal maintenance.
- Weather stations
- Soil moisture control
- Agriculture
- Waterworks
- Wastewater treatment plants
- Hydroelectric power stations
- Military use
- Roads
- Forest control
- Construction Engineering
- POM construction that aids in the release of water from the spoon
- Deep funnel
- Drainage pipe for rainwater collection
- 50cm2 funnel
- Quick calibration using a screw
- Resistant to harsh conditions
- High precision and reliability
- Easy installation
- Maintenance-free
- Long service life
- Compatible con Smartyplanet
Especificaciones Técnicas
| PARÁMETROS | ESPECIFICACIONES |
|---|---|
| Resolución | 0,10 mm 0,20 mm 0,25 mm 0,50 mm |
| Orificio | 50 cm2 |
| Diámetro interior | 159,6 mm |
| Diámetro exterior | 165 mm |
| Altura salpicadero | 170 mm |
| Peso | 380 g |
