Heated pyranometer
Solar radiation sensor and data analysis with Smartyplanet
The SP230 heated pyranometer is the ideal solution for measuring solar radiation in places with extreme weather conditions.
To ensure that the data collected by the sensor is reliable and accurate, the pyranometer has a built-in heating system.
This system ensures that the dome in which the sensor is located is completely dry at all times regardless of weather conditions.
The pyranometer is fully compatible with the Smartyplanet web platform, so the data it collects is recorded and analyzed instantly.
Category: Solar radiation, Solar radiation, Smarty Meteo, Smarty Snow
Description
Applications
Technical characteristics
The SP230 heated pyranometer is the ideal solution for measuring solar radiation in places with extreme weather conditions.
The design of this pyranometer includes a 0.2W heating system. This system keeps the sensor dry to minimize errors that can be caused by phenomena such as dew, frost, rain, or snow, which can block the sensor's operation.
The sensor is housed in a robust aluminum body and is dome-shaped.
The data collected by the sensor is accurate and reliable thanks to the system described.
The heated pyranometer is fully compatible with the Smartyplanet web platform, so the data collected by the sensor can be recorded and analyzed instantly.
The pyranometer is easy to install and requires minimal maintenance.
- Meteorological monitoring in adverse conditions
- Agriculture
- Environmental control
- Hydrological control
- Solar panels
- Heated
- Resistant to harsh conditions
- High precision and reliability
- Robust design
- Compatible con Smartyplanet
Especificaciones Técnicas
| PARÁMETROS | ESPECIFICACIONES |
|---|---|
| Tensión de alimentación | 12 VDC para el sistema de calefacción con una corriente de 15 mA |
| Salidas (Sensibilidad) | 0,2 mV/(W/m2) |
| Factor de calibración | 5 (W/m2)/mV |
| Calibración rango de salida | 0 a 350 mV |
| Incertidumbre calibración | ± 5 % |
| Repetibilidad medidas | <1% |
| Desviación largo plazo | < 2%/año |
| No linealidad | <1% hasta 1750 W/m2 |
| Tiempo de respuesta | <1ms |
| Campo de visión | 180º |
| Rango espectral | 360 a 1120 nm |
| Respuesta direccional | ± 5 % a 75° |
| Respuesta temperatura | 0.04 ± 0.04 % por C |
| Condiciones funcionamiento entorno | -40 a +70ºC 0-100% HR Sumergible hasta 30m |
| Dimensiones | Diámetro: 24mm Altura: 28mm |
| Peso (con 5m de cable) | 90g |
